MRCOOL
MRCOOL 95% AFUE 4 Ton 70,000 BTU Downflow Multi-Speed Gas Furnace
4 Ton | 120V
- 4 Ton capacity
- 95 AFUE heating efficiency
- Single compressor
- Runs on 120V power
Key Specifications
Product Overview
There's nothing like your first high gas bill of the season to make you dread a long, cold winter. If that's the boat you're in, you need to make a change. You need to invest in a powerful, high quality, and energy efficient heater like the 95% AFUE multi-positional gas furnace by MRCOOL. Unlike a lot of other furnace models, the MRCOOL 95% AFUE furnace wastes a minimal amount of fuel. This ensures most of your dollar is spent wisely rather than wasted, and that in turn means you have to spend less of those dollars to keep your house warm all winter long. Depending on the severity of winter weather where you live, that might mean the difference between a few dozen dollars or a few hundred dollars. So don't dread winter. Instead, choose the efficient, versatile and high quality heat of the MRCOOL. It's also protected by a 20 year Heat Exchanger Warranty, and a 10-Year Registered Parts Warranty.
Features
- Multi-speed high efficiency (constant torque) blower motor
- Self diagnostics saves last 10 fault codes regardless of power interruption
- Standardized widths for easy coil fit
- 10 year registered parts warranty
- 20 year heat exchanger warranty
- Aluminized steel inshot burners for smooth ignition
- Complies with California's South Coast Air Quality
- Optional LP kit
- Easily removable slide out blower design
- Constant torque motor produces consistent airflow and even temperatures
- Uses up to 1/3 less energy than a fixed-speed blower
- Left or right utility connections, removable floorbase for bottom return air, zero step horizontal conversion
Additional specifications
| UPC | 810512032600 |
|---|---|
| Series | Signature Downflow 95% AFUE Furnace |
| Configuration | Downflow |
| Heating capacity (BTU/h) | 66,000 |
| Input (BTU/h) | 66000 |
| Output (BTU/h) | 64000 |
| Airflow (CFM) | 1585 |
| Cycle (Hz) | 60 |
| Min circuit ampacity (A) | 8.4 |
| Max fuse / breaker (A) | 15 |
| Blower motor type | ECM |
| Blower motor HP | 3/4 |
| Blower speeds | 4 |
| Gas connection (in) | 0.5 |
| AHRI certified | Yes |
| ENERGY STAR certified | No |
| Heat exchanger warranty | 20 year Heat Exchanger Warranty |
| Shipping weight (lbs) | 144 |
| Country of origin | Mexico |
Documents
- Specification sheet (PDF)
- Installation manual (PDF)
- Owner's manual (PDF)
- Brochure (PDF)
- Warranty (PDF)
- AHRI certificate (PDF)
- EnergyGuide label (PDF)
WARNING: This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov.
Technical Specifications
Performance
| System Type | Gas Furnace |
|---|---|
| Tonnage | 4 Ton |
| Compressor / Stages | Single |
| AFUE | 95 |
Electrical & Fuel
| Voltage | 120V |
|---|---|
| Phase | Single Phase |
| Fuel Type | Natural Gas |
Physical & Certifications
| Dimensions (W x H x D) | 17.50 x 33.00 x 28.50 |
|---|---|
| Weight | 144.00 lb |
| Color / Finish | Gray |
Shipping & Delivery
Manufacturer Warranty
Covered by MRCOOL's limited warranty. Warranty terms are set by MRCOOL and differ by product line — whether registration is required, and whether the installation has to be performed by a state-licensed HVAC contractor, is not the same across the range. In every case coverage depends on the unit being installed according to MRCOOL's instructions and all applicable codes and permits. MRCOOL's warranty document for this model is the controlling source; ask us and we'll send you the one that applies.
