Trane 4.0 Ton Gas Fired Furnace 120000 Btu/hr Input BTU 80 % AFUE A801X120DM5SC
Model: A801X120DM5SC
SKU: A801X120DM5SC
4.0 Ton
- 120,000 BTU cooling capacity
- Built for Residential use
$1,297.00
Free Shipping
In Stock
Shipping to your area
Free shipping on qualifying equipment
Manufacturer warranty included
Licensed HVAC product support
Secure checkout
30-day returns on unused equipment
At a Glance
Key Specifications
System Type
Furnaces
Capacity
120,000 BTU
Tonnage
4.0 Ton
Fuel Type
Electric
Overview
Product Overview
Model: A801X120DM5SC
Description
The A801X120DM5SC is a high-capacity single-stage gas furnace from the Trane / RunTru A801X series. It is a multi-position, non-condensing furnace designed for upflow, downflow, and horizontal installations with a constant-torque ECM blower motor.
Specifications
- Specification Details
- Model A801X120DM5SC
- Furnace Type Single-stage induced draft gas furnace
- Installation Upflow / Downflow / Horizontal Left & Right
- Input Capacity 120,000 BTU/h
- Heating Capacity (ICS) 98,000 BTU/h
- Efficiency 80% AFUE
- Blower Motor 9-speed constant torque ECM
- Motor Size 1 HP
- Cooling Capacity Up to 5 tons
- Electrical Supply 120V / 1 Phase / 60 Hz
- Ampacity 14.1 A
- Max Fuse / Breaker 15 A
- Temperature Rise 35°F – 65°F
- Return Air Temperature 55°F – 80°F
- Heat Exchanger Tubular aluminized steel
- Ignition Silicon Nitride (SiNi) hot surface igniter
- Burners 6
- Vent Pipe Size 4-inch round minimum
- Gas Connection 1/2 inch
- Cabinet Dimensions 34" H × 24.5" W × 28.75" D
- Net Weight 152 lbs
- Shipping Weight 160 lbs
Documents
Technical Specifications
Performance
| System Type | Furnaces |
|---|---|
| Application | Residential |
| Capacity | 120,000 BTU |
| Tonnage | 4.0 Ton |
Electrical & Fuel
| Fuel Type | Electric |
|---|
Shipping & Delivery
Orders typically ship within 1-3 business days. Freight items are delivered by appointment to a curbside address; someone must be present to receive and inspect the shipment. Inspect for damage before signing. Returns are accepted within 30 days on unused, uninstalled equipment in original packaging -- return shipping and a restocking fee may apply. See our Shipping Policy and Return & Refund Policy for full terms.
Manufacturer Warranty
Covered by Trane's limited warranty. Warranty coverage generally requires installation by a licensed HVAC contractor and, on many brands, product registration after installation. Refer to Trane's warranty documentation for the full terms that apply to this model.
Professional Installation Recommended
Most HVAC equipment must be installed and connected by a licensed professional to remain safe, code-compliant, and eligible for manufacturer warranty coverage. If you're unsure about installation requirements, contact us before you order.
